Application of ASTM A182 F60 in ASME BPVC

Applicability in ASME BPVC & Temperature Limits

Forgings made from ASTM A182 Gr. F60 (UNS S32205), identical with ASME SA-182 Gr. F60, can be used for the construction of boilers and pressure vessels in accordance with ASME BPVC Section III, Section VIII Division 1, Section XII, and Section VIII Division 2, with maximum temperature limits of 600°F, 600°F, 600°F, and 400°F, respectively. Moreover, since ASTM A182 Gr. F60 was listed in Table UHA-23 of ASME BPVC Section VIII Division 1 (2019 version), the minimum design temperature shall be -20°F [-29°C] when it is used for the construction of VIII-1 pressure vessels.

Maximum Allowable Stresses | III, VIII-1, XII

Temp. °F	S, ksi
100	27.1
200	27.1
300	26.2
400	25.2
500	24.6
600	24.3

*Maximum allowable stress, S, for ASTM A182/ASME SA-182 Gr.F60, for metal temperature, not exceeding; Applicable to ASME Section III, VIII Div.1, and XII; Extracted from ASME Section II Part D Table 1A- 2019.

Maximum Allowable Stresses | VIII-2

Temp. °F	S, ksi
100	39.6
200	39.6
300	38.6
400	36.8

*Maximum allowable stress, S, for ASTM A182/ASME SA-182 Gr.F60, for metal temperature, not exceeding; Applicable to ASME Section VIII Div.2; Extracted from ASME Section II Part D Table 5A- 2019.

Tensile Strengths for Design Calculation

Temp. °F	Su, ksi
100	95.0
200	95.0
300	91.7
400	88.2
500	86.1
600	85.2
650	85.0

*Tensile strengths, S_u, of ASTM A182/ ASME SA-182 Gr. F60,  for metal temperature not exceeding; Extracted from ASME Section II Part D Table U – 2019.

Yield Strengths for Design Calculation

Temp. °F	Sy, ksi
100	70.0
150	65.1
200	62.2
250	59.8
300	57.9
400	55.2
500	53.4
600	51.6
650	50.5

*Yield strengths, S_y, of ASTM A182/ ASME SA-182 Gr. F60,  for metal temperature not exceeding; Extracted from ASME Section II Part D Table Y-1 – 2019.
